Accessories for wiring

We also offer a complete range of accessories for the wiring installation of the Schlüter-LIPROTEC system. Schlüter-KERDI-BOARD installation modules with pre-milled cable ducts are an ideal practical solution. They can accommodate the two-part cable duct Schlüter-LIPROTEC-ZKK; cables are simply inserted from the front. There is no need to thread any wires through conduits. The closed cable duct can then be sealed with the seaming tape Schlüter-KERDI-KEBA and Schlüter-KERDI-COLL-L sealing adhesive.


Schlüter-LIPROTEC-PZA is an adapter cable for connecting Schlüter-LIPROTEC-EASY plug & play components and Schlüter-LIPROTEC-PRO components. The adapter can also be used to integrate LED modules into a standard electrical installation.

Available length:
100 cm

Note: Installation must be carried out by a qualified electrician. Please note the wiring diagrams in the information supplied with the product or in the Supplementary Price List Spring 2020.



Schlüter-LIPROTEC-ZK are colour-coded low voltage cables for connecting Schlüter-LIPROTEC LED strips to a suitable power supply unit and/or receiver.

Available dimensions:
2 x 1.31 mm² (AWG)
5 x 1.31 mm² (AWG)

Available length:
25 m


Schlüter-LIPROTEC-ZS are 2-core or 5-core connecting sets for connecting Schlüter-LIPROTEC installations to a suitable power supply unit and/or receiver.

Available core count:


Schlüter-LIPROTEC-ZZK is a supply cable for connecting Schlüter-LIPROTEC-PB staircase systems to the voltage supply.

Available dimension:
2 x 0.32 mm² (AWG22)

Available length:
5 m


Schlüter-LIPROTEC-ZLR is a conduit for preparing subsequent cable installations.

Available diameter:
20 mm

Available length:
50 m


Schlüter-LIPROTEC-ZKK is a cable duct in white colour.

Available length:
2.5 m


Schlüter-LIPROTEC-Z are hollow wall or concealed junction boxes with cover.

Hollow wall junction box
Diameter: 68 mm
Height: 47 mm

Concealed junction box
Diameter: 65 mm
Height: 46 mm

Concealed junction box with cover
Dimensions (L X W X H): 87 x 87 x 60 mm


Schlüter-LIPROTEC-ZKL are 3-core or 5-core connectors

Available core count:


Schlüter-KERDI-BOARD-K are installation modules with pre-milled grooves for accommodating Schlüter-LIPROTEC cable ducts. The groove is designed to also accommodate a 19 mm-thick Schlüter-KERDI-BOARD panel or the Schlüter-LIPROTEC-LL support profile.

Available exterior dimension:
15 x 250 cm

Available heights:
19 mm
28 mm


Schlüter-DESIGNBASE-HVL is a self-adhesive bonding fleece.

Available widths:
38 mm
75 mm

Available length:
20 m


Schlüter-LIPROTEC-RKB is a self-adhesive reflector tape.

Available width:
38 mm

Available length:
50 m


Schlüter-PROCUT-PSF is a special cutting tool for precisely cutting LED tubes to size. To maintain IP-compliant waterproofing when cutting the LED strip, the LED tube must be cut at a 45° angle and closed with the supplied end cap and sealing adhesive.
